Boitier DIGITAL CH690 WHITE

DeepCool CH690 DIGITAL White Technical Specifications

• Model: CH690 DIGITAL WH (R-CH690-WHNNA0D-G-1)

• Case Type: Full Tower (Panoramic « Fishtank » Design)

• Color: Polar White

• Motherboard Support: E-ATX / ATX / Micro-ATX / Mini-ITX

  • Special Support: Compatible with Rear-Connector Motherboards (ASUS BTF / MSI Project Zero).

• Materials: ABS + SPCC Steel + Tempered Glass

• Digital Display: Dual-Status Digital Screen (Real-time monitoring of CPU/GPU/PSU usage, temperatures, and power consumption).

• Dimensions (L x W x H): 481 mm x 240 mm x 516 mm

• Net Weight: 9.8 kg

• Expansion Slots: 8

• Drive Bays: * 1 x 3.5″ HDD

  • 2+1 x 2.5″ SSD

• Front I/O Panel:

  • 1 x USB Type-C (Gen 2)

  • 2 x USB 3.0

  • 1 x Audio/Mic Combo Jack

• Cooling Support (Fans):

  • Top: 3 x 120 mm / 3 x 140 mm

  • Side: 3 x 120 mm / 3 x 140 mm

  • PSU Shroud (Bottom): 3 x 120 mm / 3 x 140 mm

  • Rear: 1 x 120 mm / 1 x 140 mm

• Radiator Support:

  • Top: Up to 420 mm

  • Side: Up to 280 mm

  • Bottom: Up to 360 mm

• Clearance:

  • Max GPU Length: 450 mm (Supports all RTX 5090/4090 models)

  • Max CPU Cooler Height: 182 mm

  • Max PSU Length: 180 mm
