PSU ACER 750W 80+BRONZE FULL MODULAIR BLACK

Acer AC-750 750W 80+ Bronze Technical Specifications

• Brand: Acer

• Model: AC-750 (Black)

• Type: ATX 12V

• Maximum Power: 750 Watts

• Efficiency Certification: 80 Plus Bronze

• Modularity: Full Modular

• Power Design: DC-to-DC Converter

• PFC: Active PFC

• Input Voltage: 200V – 240V (Full Range 90V-260V supported)

• Input Frequency: 50Hz – 60Hz

• Fan Size: 120 mm Silent Hydraulic Bearing Fan

• Protections: OVP / OPP / SCP / OCP

• Certifications: CE, RoHS

• Case Color: Black

• Cables: Flat Black Stealth Cables

Connector Configuration & Cable Length

• 1 x 24-Pin (20+4) ATX: 550 mm

• 2 x 8-Pin (4+4) EPS (CPU): 650 mm

• 2 x 8-Pin (6+2) PCI-E (GPU): 550 mm

• 1 x 12+4 Pin (PCIe 5.0 / 12VHPWR): 550 mm (on newer AC-750 revisions)

• 5 x SATA Connectors: 500 mm + 150 mm + 150 mm
